绕线设备制动器E-N线缆设备制动器KB7-A1976

技术数据

制动力F：

KBS7-1 14150 N

KBS7-2 26600 N

KBS7-3 32000 N

动态力矩

=F*[制动盘半径(m)-0.065]=Nm

Z大总磨损：:12 mm

新摩擦片厚度：13 mm

持续滑动时的热容量Qc: 20 kW

松钳Z小气压: 5 bar

图表显示数据依据如下条件:

7-1装有8根弹簧

7-2和7-3装有12根弹簧

若要减少力矩值可相应地减少弹簧数量：

7-1 6、4、2根弹簧

7-2和7-3 10、8、6根弹簧

图表指示了每毫米摩擦片磨损的力矩变化情况。

如需恢复到相应额定力矩，请按照使用手册说明进行调整。

Technical data

Braking force F:

KBS7-1 14150 N

KBS7-2 26600 N

KBS7-3 32000 N

Dynamic torque

= F*(disc radius in m - 0.065) = Nm

Max total wear: 12 mm

Thickness of new lining: 13 mm

Continuous thermal capacity Qc: 20 kW

Minimum release pressure: 5 bar

The torque values specified

are obtained with

No. 8 springs for 7-1,

No. 12 springs for 7-2 and 7-3.

Torque proportionally less

are achievable with

No. 6-4-2 springs for 7-1,

No. 10-8-6 springs for 7-2 and 7-3.

The diagram shows the torque

variation for each millimeter

of linings wear.

Adjust according to ensure the

correct torque value is achieved.
