EH270_EC_200907油漆

KCC

Korepox H.B. EH270

双组份

Two-Component

Product

Description

产品描述

A two-component, polyamide cured epoxy resin based high build coating.  It forms a hard and tough film with very good resistance to abrasion and impact and fresh and seawater, splash from petrol, jet fuel, diesel oil, lubricating oil and related products.  Limited resistance to vegetable oils and strong solvents such as ketones, esters, etc.

Not recommended for mineral acids or strong oxidizing solution. Harmless to grain cargo. It may be used in contact with food products and for fresh water tanks in accordance with FDA regulation, section 175.300.

EH270是一种双组份聚酰胺固化环氧树脂基厚浆涂料. 它会形成一层坚硬的, 不易磨损的漆膜, 具有良好的耐磨性, 耐冲击性以及耐淡水和海水性, 同时也耐来自汽油, 飞机燃油, 柴油和润滑油以及其它相关产品的溅液. 以及有限的耐植物油和强溶剂如酮类, 酯类等性能.

不推荐用于无机酸或强氧化溶液. 对谷类货物无害. 它也符合美国食品和药物管理局规范175.300章节的要求, 可以用于食品接触和淡水舱.

Recommended Use

推荐用途

As an intermediate or finishing coat for steel surface in severely corrosive environment and/or subject to mechanical wear.

Especially good for inside topcoat of container and also suitable for coating of concrete, e.g. swimming pools or tanks.

作为一种中间漆或面漆, 用于严重腐蚀性环境中的和/会受到机械磨损的钢材表面.

特别适用于作为集装箱的内表面漆, 也可用作混凝土, 如游泳池或储水池表面的涂料.

Physical Properties 物理特性

Finish and Color

外观及颜色

Flat.  White (1000), Grey (1128), Brown (2282).

平光. 白色 (1000)，灰色 (1128)，棕色 (2282).

Drying Time

干燥时间

Substrate temperature

底材温度

5℃/41℉

20℃/68℉

30℃/86℉

Set to touch

指触干

8 Hours

4 Hours

2 Hours

Dry through

硬干

48 Hours

18 Hours

12 Hours

* The actual drying time is subject to the film thickness, ventilation, humidity etc., and drying time

under other temperature conditions should be checked and informed by KCC.

* 实际干燥时间随着涂膜厚度, 环境通风程度和湿度而不同, 其他温度条件下的干燥时间请咨询 KCC.

Solids by Volume

体积固体份

Approx. 55 % (Determined by ISO 3233)

约 55% (按ISO 3233测定)

Theoretical Spreading Rate

理论涂布率

5.50㎡/L in 100㎛, 13.75㎡/L in 40㎛ dry film thickness on a smooth surface.

光滑表面上, 干膜厚度为100㎛时, 则理论涂布率为5.50㎡/L.

干膜厚度为40㎛时, 则理论涂布率为13.75㎡/L.

Specific Gravity

比重

Approx. 1.3 ~ 1.4 for Mixture of base and Curing agent.

混合后, 约 1.3 ~ 1.4

Flash Point

闪点

base [ EH270 PTA ] : 26℃ / 79℉ (Closed Cup)

Curing Agent [ EH270 PTB ] : 29℃ / 84℉ (Closed Cup)

主剂 [ EH270 PTA ] : 26℃/79℉ (密闭杯)

固化剂 [ EH270 PTB ] : 29℃/84 ℉ (密闭杯)

Disclaimer :  The information in this data sheet is believed to the best of our knowledge based on laboratory test and practical experience.  However, there are many factors affecting the performance of product and the product quality itself, so we are not able to guarantee without the confirmation of the purpose of using the product from us in writing.  We reserve the right to change the data without notice and you should check that this data sheet is current prior to using the product.

此技术资料根据实验与经验得出, 可确保其准确性, 但由于产品特性及影响产品品质的诸多因素, 没有经过本公司确认而任意更换产品使用用途而发生的一切后果, 本公司不负任何责任. 在使用本产品之前, 应确认产品技术资料是否为新版本.

KCC

Korepox H.B. EH270

双组份

Two-Component

Application Details 涂装指南

Surface

Preparation

表面处理

Remove any oil, grease, dirt and any other contaminants from the surface before painting by proper method such as solvent cleaning and fresh water washing, etc.

* Steel : Blast cleaning to Sa2.5 or Power tool cleaning to St3, etc.

* Concrete, asbestos cement, etc. : Wash down with a 3% solution of hydrochloric or phosphoric acid in fresh water and must be dried.

涂装前使用适当方法例如溶剂清洁和淡水冲洗等清除待涂装表面所有油,脂,灰尘和其它污染物.

* 钢材: 喷砂清洁至Sa2.5或动力工具清洁至St3.

* 在混凝土, 石棉水泥等上, 用添加3%的盐酸或磷酸溶液的淡水进行清洗, 并保持干燥.

Application

Conditions

施工条件

The surface should be completely cleaned and dried. Application and curing to take place at temperatures above 5℃(41℉). Do not apply when relative humidity is above 85%.  The surface temperature should be at least 2.7℃(5℉) above dew point to prevent condensation. In confined spaces, provide adequate ventilation during application and drying.

涂装表面应完全清洁和干燥. 相对湿度不能超过85%, 表面温度至少高于露点2.7℃(5℉)避免结露. 封闭空间作业时提供清洁流通空气以助于溶剂挥发.

Mixing

混合

base (Part A) : Curing Agent (Part B) = 4 : 1 (by volume)

Mix thoroughly together prior to application in the proportions with power agitator as delivered.

主剂 : 固化剂 = 4 : 1 (体积比)

施工前按比例混合使用动力搅拌器充分搅拌.

Pot Life

适用期

8 Hours at 20℃/68℉

在20℃/68℉, 8小时

Preceding Coat

前道涂层

Korepox Zinc Rich Primer EZ175 or according to specification.

Korepox Zinc Rich Primer EZ175或根据规范.

Thinning

稀释

Thinner No. 024.

Do not dilute each components separately, only the mixture.

稀释剂 No. 024.

不要单独稀释各组份, 应稀释混合物.

Application Method

施工方法

Spray (Airless or Air), Roller or Brush application.

For airless spray application ;

Nozzle orifice : 432㎛ ~ 584㎛ (0.017″ ~ 0.023″)

Output pressure : 14.5 MPa

Fan : 30^o ~ 60 ^o

(Airless spray data are indicative and subject to adjustment.)

刷涂, 辊涂或喷涂 (有气或无气) 施工.

无气式喷涂 ;

喷嘴口径 : 432㎛ ~ 584㎛ (0.017″ ~ 0.023″)

喷口压力 : 14.5 MPa

喷射扇面 : 30^o ~ 60^o

(无气式喷涂的有关数据可根据指导进行调整.)

Typical

Film Thickness

典型漆膜厚度

100㎛ dry.

May be specified in another film thickness than indicated depending on purpose and area of use.

干膜厚度100㎛.

干膜厚度根据使用用途及部位而异.

Disclaimer :  The information in this data sheet is believed to the best of our knowledge based on laboratory test and practical experience.  However, there are many factors affecting the performance of product and the product quality itself, so we are not able to guarantee without the confirmation of the purpose of using the product from us in writing.  We reserve the right to change the data without notice and you should check that this data sheet is current prior to using the product.

此技术资料根据实验与经验得出, 可确保其准确性, 但由于产品特性及影响产品品质的诸多因素, 没有经过本公司确认而任意更换产品使用用途而发生的一切后果, 本公司不负任何责任. 在使用本产品之前, 应确认产品技术资料是否为新版本.

KCC

Korepox H.B. EH270

双组份

Two-Component

Recoating Interval

复凃间隔

At 20℃/68℉, Minimum : 16 Hours

Maximum : 30 Days

Prior to overcoating, remove the oil, salt, chalking material and any other contaminants on aged coating film completely by proper cleaning method such as solvent cleaning and/or fresh water washing.

复涂之前采用适当的清洁方式, 例如溶剂清洗和/或淡水冲洗彻底清洁前道涂层表面, 去除油份, 盐份, 粉化物质和其它污染物.

Subsequent Coat

后续涂层

Korepox Enamel ET574, Korepox Topcoat H.B. ET5740, Korepox Topcoat H.B. ET5745, or according to specification.

Korepox Enamel ET574, Korepox H.B. ET5740, Korepox Topcoat H.B. ET5745 或根据规范.

Shelf Life

有效期限

12 Months minimum at 25℃. (Subject to re-inspection thereafter.)

在25℃的条件下存贮期为12个月以上. (应以实际检验结果为准)

Heat Resistance

耐热性

Continuous : 93℃/ 200℉ (Non-immersion service)

Non-continuous : 121℃/250℉ (Non-immersion service)

持续的 : 93℃/200℉ (非沉浸区)

间断的 : 121℃/250℉ (非沉浸区)

Chemical Resistance

Acids

酸

Alkalis

碱

Solvents

溶剂

Salts

盐

Water

水

耐化学性

Splash & Spillage

溅液

Fair

一般

Excellent

非常好

Good

好

Excellent

非常好

Excellent

非常好

Fumes

烟雾

Very Good

很好

Excellent

非常好

Very Good

很好

Excellent

非常好

Excellent

非常好

Standard

Packing Unit

标准包装规格

16 L [ EH270 PTA : 12.8L, EH270 PTB : 3.2L ]

16Ｌ [ EH270 主剂 : 12.8L, EH270 固化剂 : 3.2L ]

Remarks

备注

Protect skin and eyes from direct contact with liquid paint, and avoid prolonged breathing of solvent vapors.

Use with adequate ventilation.

Respiratory protection is recommended during application in confined spaces or stagnant air.

Keep away from sparks and open flames.

保护皮肤和眼睛避免直接接触液态涂料，避免长时间呼吸溶剂蒸汽.

通风要充分.

在封闭空间或空气不流动场所涂装时, 推荐戴好有效呼吸保护装置.

远离火花和火种.

Issued

发布于

July 2009

2009年7月
